| Engine | Manufacturer – Yanmar Engine model – 3TNV86CT-MJT Engine power (gross) – SAE J1995 rated power: 28.5 kW – 38.2 hp – 38.7 PS at 2600 rpm Power take-off (PTO) power – eHydro transmission: 22.2 kW – 29.8 hp Rated engine speed – 2600 rpm Injection pump type – High pressure common rail direct injection Aspiration – Turbocharged Emissions compliance – Final Tier 4 Cylinders/displacement – Three cylinders: 1.57 L – 95.7 cu in. Number of cylinders – 3 Cylinder liners – Cast-in-block Bore and stroke – 86 x 90 mm – 3.4 x 3.54 in. Compression ratio – 19.1:1 Lubrication – Pressurized Cooling system – Liquid Air cleaner – Dual element Engine torque at rated speed – 105 Nm – 77.4 lb-ft Fuel tank capacity – OOS: 37.4 L – 10 U.S. gal. – Cab eHydro transmission only: 47.6 L – 12.6 U.S. gal. |
| Transmission | Type – John Deere 24F/12R PowrReverser Transmission: 40 km/h – 25 mph |
| Hydraulics | Pump rated output Steering Pump type – Single gear Maximum operating pressure – 172 bar – 2495 psi Remote control valves available – Up to six rear remotes   |
| Rear hitch | Hitch category (SAE designation) – Category 2: 2500 kg (5500 lb) standard lift at 610 mm behind hitchpoint Maximum lift capacity behind lift points – Standard: Category 2 with heavy duty lift: 3318 kg – 7300 lb |
| 3-point hitch | Type – Category 1 Lift capacity, 24-in. behind link arms – 995 kg – 2194 lb |
| Power take-off (PTO) | Standard – Independent rear: 540 rpm Control – Lever and switch Clutch – Wet disk Brake (for mid and rear PTO) – Wet disk |
| Cab | Compliance – Complies with OSHA, SAE, and CSA standards for rollover protection Visibility – 360 degree (angle) Noise rating – 80 dBA |
- Cab
- Transmission: Hydro
- Front Axle: MFWD
- Loader: Yes
